We R&D the UST-1200 rear panel verision in 2023,which could loading 7 units in 40ft container.But with less sun power then UST-1200 normal version .Customer could choose suitable version depend the load consumption.
| Place of Origin: | China |
| Brand Name: | UNIV |
| Model Number: | UST600L |
| Certification: | CE/ISO9001 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | plywood/ wooden case/ EPE foam |
| Delivery Time: | 45days |
| Payment Terms: | 30% T/T,Balance before delivery |
| Supply Ability: | 200Units/month |
Construction sites,Parking lots and outdoor spaces,Roadworks and maintenance，Mining and remote locations,Temporary Security Needs
High quality, More than 16 years of production experience，Products exported to more than 100 countries
| Solar Panel | 4 × 460W |
| Panel Lifting | 30°~38°,Electric Lifting |
| GEL/LFP Battery | 8 × 200Ah DC12V |
| Battery Capacity | 19200Wh 80% DoC |
| System Voltage | DC48V |
| LED Lamp | 4 × 200W,120000Lms |
| Rotation | 350° Electric |
| Tilt | 90° Electric |
| Controller | 40A MPPT |
| Mast & Height | 5 Sections 9M |
| Mast Lifting | Electric Winch |
| Trailer Standard | US / AU / EU |
| Hitch | 2'' Ball / 3'' Ring |
| Brake | Mechanical |
| Axle | Single |
| Tire | 15 inch |
| Outriggers | 4 × |
| Forklift Holes | 2 × |
| Wokring Temp | -35℃~60℃ |
| Charging Time | 9.3 hours |
| Running Time | 19.2 hours |
| Dimension(mm) | 3650*2250*2800 |
| Weight | 1600kg |
| QTY in 20' / 40' | 2 units / 5 units |
| Inverter | Optional |
| AC Charge | Optional |
| backup generator | Optional |
| Wind turbine | Optional |
